Customised Automated Trigger Assembly Machine with PLC Control and Touch Screen Operation for High Efficiency 4500pcs/h

Customised Automated Trigger Assembly Machine with PLC Control and Touch Screen Operation for High Efficiency 4500pcs/h

大画像 :  Customised Automated Trigger Assembly Machine with PLC Control and Touch Screen Operation for High Efficiency 4500pcs/h

商品の詳細:
起源の場所: 中国
ブランド名: Sencan-PT25
証明: CE
モデル番号: SC-2025
お支払配送条件:
最小注文数量: 1セット
価格: Deliberation
パッケージの詳細: 木製ケース
受渡し時間: 90営業日
支払条件: T/T、L/C
供給の能力: 1か月あたり3セット
詳細製品概要
適用される製品: トリガー組立機 生産効率: 99%
オペレーター: シングル 保証: 1年
生産タイプ: 循環ルート 容量: 4500pcs/h
ハイライト:

4500pcs/h Trigger Assembly Machine

,

PLC Control Automated Assembly Machine

,

Touch Screen Operation Daily Necessities Assembly Machine

Customized Automated Trigger Assembly Machine
Engineered for simple operation and high efficiency in trigger sprayer assembly applications
Key Features
  • Linear sliding rail conveying system driven by servo motor for precise intermittent movement
  • Static fixtures with precise positioning devices and secondary positioning at each workstation
  • Independent manipulators at each station for simplified daily maintenance
  • Cylinder-powered manipulators for faster spare parts changes and easier debugging
  • Optional feeding plate enclosure to reduce production noise
  • Integrated detection after each assembly process to eliminate defective products
  • Complete PLC system control with touch screen operation interface
Technical Specifications
Applicable Products Trigger Sprayer
Production Speed 1,500 - 4,500 pieces/hour (customizable to customer requirements)
Product Qualification Rate Above 98%
Operation Rate Above 95%
Power Source AC380V, 50Hz, 4kW/hour
Dimensions Actual size varies with production speed requirements
Weight Approximately 3,000 kg
Operator Requirement 1 person per machine set
