商品の詳細:
お支払配送条件:
|
| 適格料金: | 98％ | 製品認証: | CE、ISO |
|---|---|---|---|
| 自動化レベル: | 完全に自動化されています | 主力: | サーボ+シリンダー |
| 製品タイプ: | アセンブリマシン | アセンブリメソッド: | オートマティック・フィード・アンド・アセンブリ |
| 保証期間: | 1年 | 電圧: | 220V |
| アドバンテージ: | 両方のサイズが一緒に組み立てられます | ケーブルサイズ: | 三相5線式 |
| 容量: | 高い | 検出システム: | 光電センサー |
| アクティブな力: | サーボモーター | ||
| ハイライト: | fully automated lotion pump machine 220V,lotion pump assembly machine 1500-2500pcs/hr,daily necessities assembly machine with warranty |
||
Features
1. Linear sliding rail conveying system will be applied and driven by servo motor to make intermittent movement, fixtures will be in a static state during assembly with precise positioning devices. Each workstation is equipped with a secondary positioning to improve qualified rate of product.
2. Manipulators of each station are independent, simple and easy for daily maintenance.
3. Manipulators are powered by cylinders, shorter time for spare parts change, simpler for debugging and maintenance.
4. The tube insertion process will be silicone oiled automatically, oil storage is 4L.
5. Enclosure for feeding plate can be equipped to reduce noise during production.
6. Each assembly process is followed by detection to ensure there will be no defective products in qualified products.
7. Whole equipment controlled by PLC system and touch screen operation.
Properties
|
Applicable products |
lotion pump shampoo pump water sprayer trigger sprayer perfume pump spray nozzle |
|
Production speed |
1500-2500pcs/hr (according to customer’s requirement) |
|
Rate of qualified product |
Above 98% |
|
Rate of operation rate |
Above 95% |
|
Power source |
AC380V, 50Hz, 4kw/hr |
|
Dimension |
Actual size varied with different production speed |
|
Weight |
About 3000kg |
|
Operator |
1set/person |
